  #41
Old 03-14-2015, 05:42 PM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Here is the progress so far.

Got the new bumper cover, seems like a good fit so far. Doesn't have that blue tint that lots of these bumpers have, which is nice.





This is the new driver side mount, it's not pretty but it is functional. Will be adding some more structure to keep it rigid later on.



Finally able to lift up the beast!



Cut a little off the subframe to clear the trans, migd and sanded smooth it looks almost factory.



The start of the rear mount, added a ton of strength to the engine mount system.



You fit owners will notice that I removed the factory rear mount and welded a 1/4" plate over where it mounted. That was about a 2 hour job, but the new system was totally worth all that extra work. Lots of exhaust room on both sides of this piece.



Got a factory replacement set of headlights, went with the base versions, not really into shiny stuff.



Should have tons of room still in the bay.



This is where I am now stuck. We have used quite a few Tong Yang hoods, they all fit pretty alright, never perfect, but close enough.



This one is having a bunch of trouble though, the rear is 1/2" too low and about 1/4" too far back. I moved the hinges as far forward as they can go.









I'm wondering if the hinges got bent in the accident, but they seem to be okay, no cracking paint or anything. Probably end up spacing them up and boring out the mount holes a bit to get it aligned. Can't build the front bumper until the hood and headlights get lined up.



Other than that I got the AC condenser and radiator ordered.
Reply With Quote
  #42
Old 03-14-2015, 06:13 PM
Member

Join Date: Jun 2014
Location: Italy
Posts: 81
very nice!
Reply With Quote
  #43
Old 03-14-2015, 07:00 PM
jgpoirier's Avatar
Member

Join Date: Mar 2012
Location: Calgary, AB
Posts: 130
This, is fucking sweet! Ever plan on doing this to a GD? Nice work man
Reply With Quote
  #44
Old 03-14-2015, 07:35 PM
Member

Join Date: Aug 2014
Location: Connecticut
Posts: 1,236
WOW! Amazing work! This Fit is gonna have balls like a brass monkey with a 6 banger. Hope it handles as well as stock!
Reply With Quote
  #45
Old 03-14-2015, 09:02 PM
Fitguy07's Avatar
Member
5 Year Member
iTrader: (1)

Join Date: Apr 2009
Location: Bergen County, NJ
Posts: 777
Crazy, just crazy. I never thought about a 6 in the Fit, good luck with the build!
Reply With Quote
  #46
Old 03-14-2015, 09:42 PM
BMW ALPINA's Avatar
Member
iTrader: (1)

Join Date: Jan 2013
Location: Mission Viejo, California
Posts: 2,087
Wow, Amazing Build !
I will follow your thread until your build is completed,
I am sure there will be plenty of lesson to be learned from this Amazing Build !
Thanks
Reply With Quote
  #47
Old 03-14-2015, 11:19 PM
555sexydrive's Avatar
Member
5 Year Member

Join Date: Oct 2009
Location: Zama-Shi, Japan
Posts: 2,310
This is where the Barbara Streisand USDM Fit shines. Those extra inches up front sure help. Looks like tons of space available. Really looking forward to the end result. Not into straight line really, interested how this thing goes left and right. Will this strictly be a one-off or plans to later offer a kit? As you said, much cheaper getting the 6 versus a K.
Reply With Quote
  #48
Old 03-15-2015, 04:05 AM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Quote:
Originally Posted by jgpoirier View Post
This, is fucking sweet! Ever plan on doing this to a GD? Nice work man
My original plan was to do an older chassis like that, but this one showed up first and I like the headlights more on these. Sort of a mean adorable look to this car that I love.

Quote:
Originally Posted by 555sexydrive View Post
Will this strictly be a one-off or plans to later offer a kit? As you said, much cheaper getting the 6 versus a K.
So far I only plan on doing a one off. Haven't seen a ton of k series fits yet, as the car gets older that might change though. One of the weird parts about making a kit would be the rear mount, the J mount for the rear is so much higher than the stock engine that it might be a trick to get the kit to work universally.
Reply With Quote
  #49
Old 03-16-2015, 03:23 PM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Great news! After hours of fighting with some weird key problem the ignition now works.



Turns out part of the key was incorrectly cut, we found that out after completely removing the ignition and filing town one of the tumbler pins. Weird problem, glad that part is finally sorted out!
Reply With Quote
  #50
Old 03-16-2015, 03:48 PM
Myxalplyx's Avatar
Member

Join Date: May 2014
Location: Delaware
Posts: 1,702
Was reading up a little about the 001–2003 Acura 3.2 CL Type S that this engine came out of. Will you consider something ridiculous like adding that Comptech supercharger to it that was introduced in 2003? Seems it raised the output to 369 hp (275 kW) @ 6800 rpm, 302 lbft (409 Nm) @ 5400 rpm (With Comptech Headers and exhaust of course but you are fabbing your own anyways).


Yes, I know....it's a silly question. Can't hurt to ask! May as well have fun with this thread.

Last edited by Myxalplyx; 03-16-2015 at 03:54 PM.
Reply With Quote
  #51
Old 03-16-2015, 04:55 PM
counterFIT's Avatar
Member

Join Date: Jan 2015
Location: Raleigh, NC // Columbia, SC
Posts: 410
Pretty sure this is gonna change the Fit tuning scene for good. Keep up the good work!
Reply With Quote
  #52
Old 03-16-2015, 06:40 PM
Fitguy07's Avatar
Member
5 Year Member
iTrader: (1)

Join Date: Apr 2009
Location: Bergen County, NJ
Posts: 777
Down the strip, it will undoubtedly be a fast monster.


Like others, I'm also interested to see how it corners and handles with the Front/Rear weight distribution tilting even more up front, maybe to 70/30 now?


Upgrading to bigger brakes when all is said and done should be beneficial too.
Reply With Quote
  #53
Old 03-16-2015, 07:40 PM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Quote:
Originally Posted by Myxalplyx View Post
Was reading up a little about the 0012003 Acura 3.2 CL Type S that this engine came out of. Will you consider something ridiculous like adding that Comptech supercharger to it that was introduced in 2003? Seems it raised the output to 369 hp (275 kW) @ 6800 rpm, 302 lbft (409 Nm) @ 5400 rpm (With Comptech Headers and exhaust of course but you are fabbing your own anyways).


Yes, I know....it's a silly question. Can't hurt to ask! May as well have fun with this thread.
I'm working on an m90 adapter right now, might just clear the hood. Either that or a Rotex like andy from the J forums did on his TL.



Quote:
Originally Posted by Fitguy07 View Post
Down the strip, it will undoubtedly be a fast monster.


Like others, I'm also interested to see how it corners and handles with the Front/Rear weight distribution tilting even more up front, maybe to 70/30 now?


Upgrading to bigger brakes when all is said and done should be beneficial too.
When I pulled off the wheels I was impressed by the size of the rotors on this car. Same size as what we upgrade our civics too. I don't plan to run the car on super sticky tires so this setup with a more aggressive pad should be perfect.

I will also scale the car when I get her finished. My EG is 65/35 without me in it. People get really hung up on getting to 50/50, it depends on the car and driver though. Same way people seem to think that swaybars are ALWAYS faster.
Reply With Quote
  #54
Old 03-16-2015, 09:31 PM
Member
5 Year Member
iTrader: (1)

Join Date: Aug 2009
Location: NH
Posts: 245
Quote:
Originally Posted by PinkBatman View Post

Got the new bumper cover, seems like a good fit so far. Doesn't have that blue tint that lots of these bumpers have, which is nice.

This is where I am now stuck. We have used quite a few Tong Yang hoods, they all fit pretty alright, never perfect, but close enough.



This one is having a bunch of trouble though, the rear is 1/2" too low and about 1/4" too far back. I moved the hinges as far forward as they can go.









I'm wondering if the hinges got bent in the accident, but they seem to be okay, no cracking paint or anything. Probably end up spacing them up and boring out the mount holes a bit to get it aligned. Can't build the front bumper until the hood and headlights get lined up.

Hi Pink,
Is the bumper OEM? what it run you for cost.

That hood looks nice but some funky fitment there.
If you want I can grab the stock hood dimensions for you to confirm its the hood or the Chassis/hinges. Let me know if you need specific pics of anything to help with the rebuild.

Last edited by slimchriz; 03-20-2015 at 02:05 PM.
Reply With Quote
  #55
Old 03-16-2015, 09:46 PM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Quote:
Originally Posted by slimchriz View Post
Hi Pink,
Is the bumper OEM? what it run you for cost.

That hood looks nice but some funky fitment there.
If you want I can grab the stock hood dimensions for you to confirm its the hood or the Chassis/hinges. Let me know if you need specific pics of anything to help with the rebuild.
I think I pretty well got the hood figured out, thanks for the offer though.

The bumper is another Tong Yang part. I got it on eBay shipped for about $120.
Reply With Quote
  #56
Old 03-16-2015, 10:20 PM
wzlfit's Avatar
Member

Join Date: Oct 2014
Location: lakewood, ohio
Posts: 240

this is the least weasel
It's the smallest member of the weasel family
has the hardest bite of any mammal (per size)
It's primary prey is twice its size and speed but it outsmarts/maneuvers
I think it's a good animal representation of the fit.


this is a wolverine
a larger member of the weasel family
Can out posture a grizzly bear
relentless hunter
cross great distances in sort times
If my ge is a least weasel yours would be a wolverine.

Great thread you got me exited enough to order my next upgrade!
Reply With Quote
  #57
Old 03-18-2015, 03:14 AM
john21031's Avatar
Member
5 Year Member

Join Date: Apr 2009
Location: SoCal/Castaic
Posts: 840
Prompts for the effort but I can't help but think of these:



Reply With Quote
  #58
Old 03-18-2015, 12:29 PM
BMW ALPINA's Avatar
Member
iTrader: (1)

Join Date: Jan 2013
Location: Mission Viejo, California
Posts: 2,087
Quote:
Originally Posted by john21031 View Post
Prompts for the effort but I can't help but think of these:
Please remember that many manufacturer do this kind of engine transplant.

The C-Class Mercedes had engine range from tiny 1.8 liter to V8 engine (AMG version),

The 3 series BMW had engine range from tiny 1.6 liter to V8 engine in the previous M3

The Audi A6 had engine range from small 4 cylinder to V10 (the old RS6)
and so does the older 5 series M5 with the V10.

and many more example,

so as long as the suspension, the tire and the brake get upgraded, (especially the front),
I don't see any major problem with this engine transplant on a Honda Fit.
Reply With Quote
  #59
Old 03-18-2015, 07:04 PM
Member

Join Date: Mar 2015
Location: New Zealand
Posts: 65
Quote:
Originally Posted by PinkBatman View Post
Great news! After hours of fighting with some weird key problem the ignition now works.



Turns out part of the key was incorrectly cut, we found that out after completely removing the ignition and filing town one of the tumbler pins. Weird problem, glad that part is finally sorted out!
Are you sure 140mph is going to be enough?
Reply With Quote
  #60
Old 03-20-2015, 02:02 AM
Member
Thread Starter

Join Date: Mar 2015
Location: MT
Posts: 51
Quote:
Originally Posted by c3kay View Post
Are you sure 140mph is going to be enough?
I'll let you know when it is finished
Reply With Quote
