anybody thought of both high and low beams on at once?
#1
anybody thought of both high and low beams on at once?
my recently departed 91 crx si had a great feature that I really liked- when the high beams were on the lows stayed on. granted, they were separate lights, but I miss this because the combined lights were great! I talked to a friend who messes with mostly chevy stuff and we were talking about lighting mods and he said he did a mod to have both filaments on at the same time when in high beam mode (dual element bulb). I was wondering if anyone here had thought of doing something like this? i wonder what the added heat load would be and if if could possibly melt something in the headlight housing. anyone?
#3
yeah, I know. I was wondering if someone HAS or thought about maybe putting a jumper in to enable BOTH elements to be on in high beam mode. thus enabling a whole lot of light for the road from both elements.( plus fogs!)
#4
if u pull the high beam flash stalk about halfway, u can get both low and high at the same time
#9
eh i don't think you people get it...i think the op is saying that if both the low and high beam filament stays on WHEN he needs to use the highs it would be more useful...not to drive around with both on. and i have to agree with the op...having both filament on would be much better than only one. i've driven a camry that uses dual filament bulbs and when i needed the highs it wasn't as good as the dual bulb setups.
#10
right-somewhat. I mean when lows beams are on, just the low filament is on, but when the highs are on, the low filament STAYS on when the high filament comes on, resulting in a more full, uniform lighting field.
#12
eh i don't think you people get it...i think the op is saying that if both the low and high beam filament stays on WHEN he needs to use the highs it would be more useful...not to drive around with both on. and i have to agree with the op...having both filament on would be much better than only one. i've driven a camry that uses dual filament bulbs and when i needed the highs it wasn't as good as the dual bulb setups.
to say nothing one would seem average
to post the wrong answer or to post an answer to a question not asked........
on the canadian model all u have to do is bypass the low beam cut relay....on the us u have to rewire the stalk
Last edited by TheImmortal; 02-01-2009 at 04:19 PM.
#14
Well being as the 105w apiece they'll be consuming it should put out similar heat to sid's 110w bulbs. He hasn't burned his reflectors yet but then again he just put them in.
If you afford to replace the expensive headlight assemblies if they get ruined, it's not hard:
-run separate power from batt to relays
-one relay for low, one relay for high, and one relay to cross between their output wires when highbeam is on
-make sure your wires and relays can take the amperage. Put properly-sized fuses on your power wires.
Myself, I'd buy connectors for the stock harness so I don't have to cut it, and have 6 relays total to keep the heat down, each set of 3 bolted to a bracket. Being me and my love for overkill I'd probably run 8-gauge wire for power, and rig a separate ground for each side.
I'm gonna wait to see what sid says about the heat first.
If you afford to replace the expensive headlight assemblies if they get ruined, it's not hard:
-run separate power from batt to relays
-one relay for low, one relay for high, and one relay to cross between their output wires when highbeam is on
-make sure your wires and relays can take the amperage. Put properly-sized fuses on your power wires.
Myself, I'd buy connectors for the stock harness so I don't have to cut it, and have 6 relays total to keep the heat down, each set of 3 bolted to a bracket. Being me and my love for overkill I'd probably run 8-gauge wire for power, and rig a separate ground for each side.
I'm gonna wait to see what sid says about the heat first.
Last edited by polaski; 02-02-2009 at 02:02 AM.
#16
I live in an urban area, so I almost never use my high beams. Even on isolated highways, I find I'm not out-driving my low beams even a few clicks over the speed limit.
But having lived and driven through rural Texas at night, I can certainly understand the desire to run as much light as possible, if not to see the road, then to see the animals that might have wandered onto the road.
It's true that Hondas usually have thicker gauge wires for the headlights. That's because they're switch grounded instead of bulb grounded. Meaning bulbs are fed power directly from the battery (well, after large fuses), then when the switch is turned on, it grounds the circuit and turns the lights on. However, I'd still be wary about running both the high and low beams together due to heat issues at the bulb. I've seen bulbs that have exploded inside the headlight. When that happens, you have no choice but to buy new headlights.
But having lived and driven through rural Texas at night, I can certainly understand the desire to run as much light as possible, if not to see the road, then to see the animals that might have wandered onto the road.
It's true that Hondas usually have thicker gauge wires for the headlights. That's because they're switch grounded instead of bulb grounded. Meaning bulbs are fed power directly from the battery (well, after large fuses), then when the switch is turned on, it grounds the circuit and turns the lights on. However, I'd still be wary about running both the high and low beams together due to heat issues at the bulb. I've seen bulbs that have exploded inside the headlight. When that happens, you have no choice but to buy new headlights.
#17
There is a very easy mod you can do so your fogs won't turn off when the highbeams come on. I know this isn't what you are asking about, but that's the route I've gone to have more light with the high beams. It definitely helps on highways with seeing small animals in your peripheral.
